P3W-E - ASUS
Single Slot 1 for Pentium ® III Processor Slot 1 for Intel Pentium® III / Pentium® II 400~600+ MHz with Built-in 512KB L2 Cache Support 133MHz / 100MHz Front Side Bus (FSB) Processor Supports ASUS® Socket 370 CPU Card for PPGA CeleronTM Processors External Frequencies, Vcore & Vio Adjustable Intel® 810E Chipset GMCH1, ICH1, FWH Chipsets Supports Pentium® III/ II Processor CPU 133MHz/100MHz FSB Built-in 3D Graphics with 4MB SDRAM Display Cache as Z-Buffer Supports Dynamic Display Memory Plus (DDM+) Technology Supports 6 PCI, UltraDMA/66, AC ' 97, Low Pin Count I/O and Alert-On-LAN Bundled with I/O Controller Hub #1 (ICH1) and Firmware Hub (FWH) 3 x DIMM Sockets for Memory 3x 168-Pin DIMM Sockets Support 8MB to 512MB 3.3V PC100 SDRAM Extra 1 DIMM for More Flexible System Memory Combinations ACPI Suspend-to-RAM Power Plane Ready Intel® 82559 LAN Controller (Optional) 10/ 100Mbps Auto-Detection & Negotiation Alert-On-LAN, Wake-On-LAN & Full/Half Duplex Support Sophisticated Controller with MAC/PHY Integration PanelLinkTM Digital Display Controller (Optional) Silicon Image® Sil154 Transmitter Supports TMDS Technology Digital-to-Digital with no Analog Conversion Much Finer & Sharper Display Quality Than CRT Analog Display Adopt by VESA® & Compaq® /HP® /Intel® /IBM® PCI/ISA Slots 5 PCI + 2 ISA for Maximum Expansion, 6 PCI version only for PC ' 99 ISA Bridge Required with Existence of ISA Slot PCI 2.2, 32-bit Bus Master Slots AMR Connector for Modem New Low Pin Count 46-pin Audio/Modem Connectors Supports AMR-based AMC/AC/MC Adapters Smart BIOS - Jumper Free Award® 4Mb BIOS with Full ACPI, DMI, Green, PnP, Trend® ChipAway Virus (TCAV) & Symbios® SCSI Jumper Setting by S/W (JumperFreeTM) Vcore, CPU/PCI Ratio & Boot Media Selections PC ' 99 Color-Coded I/O Ports 2 x USB Ports (Support Hot-Plug Function), 1x VGA Port, 1x RJ-45 Port (LAN Version Only) 2 x Serial Ports, 1x Parallel Port (EPP, ECP) 1 x PS/2 Keyboard Port, 1 x PS/2 Mouse Port 1 x Floppy Port (Up to 2.88MB, 3Mode) 1 x Game / MIDI Port, Line-In /Out /Speaker Ports UltraDMA/66 IDE Ports 2 x UltraDMA/66 Bus Master IDE (Up to 4 IDE Devices) 80-pin Cable Backward Compatible Legacy ATAPI Devices ATAPI IDE CD-ROM, CD-R, CD-RW, and LS-120 Supports Crystal® CS4280 PCI Audio Controller (Optional) H/W 3D Audio Hardware Accelerator for Professionals Supports 3D Surround & Positioning, and Full & Half Duplex YAMAHA® XG High-end Software Wavetable & Utility Bundled Varies Overclocking Setting CPU Clock: 66MHz - 153MHz 22 Sets Speed Selection SDRAM Clock: 100MHz - 142MHz 22 Sets Speed Selection Maximum Speed Setting: CPU - 153MHz SDRAM - 115MHz (Overclocking is for Experimental Purpose Only) ATX 20-pin Power Connector ATX 20-pin Power Connectors for 3V, 5V, 5VSB and 12V Soft Power Off & Keyboard Power On Supported Wake-Up on Modem, LAN, Keyboard, Mouse & RTC Timer AC Power Loss Recovery Supports Board Size ATX Form Factor with size : 20.7cm x 30.5cm (8.15" x 12.0") CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : ASUS Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: |
|
