K7S5A V1.X - ECS Elitegroup
DDR motherboard for AMD® K7 socket A processors with 266/200 MHz FSB Integrated with the most advanced technologies: Suspend to RAM Keyboard power on Hardware monitoring LAN/Modem wake up PROCESSORS 462 pin Socket A supports the AMD® K7 processors Athlon XP / Athlon / Duron processors CHIPSET SiS® 735 System Chipset Super I/O and LPC - ITE8705F System Hardware Monitor: Built-in ITE8705 LAN: MAC integrated in SiS®735 & PHY on board (Optional) AC97 Audio Codec SYSTEM BIOS AMI 2Mb Flash EEPROM Supports Plug and Play 1.0A, AMP 1.2, Multi Boot, DMI Support for ACPI revision 1.0 specification MEMORY 2 DDR DIMM sockets and 2 DIMM sockets support (can not be used simultaneously) Two 184-pin DDR SDRAM (DDR200, DDR266) or Two 168-pin 3.3V SDRAM (PC100, PC133) Maximum: 1.0GB (DDR or SDRAM) I/O INTERFACE Supports Plug and Play function PS/2 keyboard and PS/2 mouse connectors Dual USB ports and an optional LAN connector 1 - EPP/ECP mode parallel port 2 - 16550 high-speed serial I/O ports Audio ports (Line-in, Line-out, Mic-in, CD-in and game port) Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 33/66/100) Supports 360K~2.88M Byte, 3 mode FDDs or LS120 ATX power supply connectors Ports, headers and others: IrDA header Extra USB header Two CD-In headers Front Panel MIC/Line-Out header HDD LED, ACPI MSG LED, Reset Switch, Power Switch headers CPU and case fan headers Modem Ring Wake Up Header RTC & BATTERY SiS®® 735 included 256 bytes of CMOS SRAM With CMOS hardware clear jumper EXPANSION SLOTS 5 PCI slots, 1 4X AGP slot, 1 AMR slot FORM FACTOR ATX (304mm*244mm), 4 Layers CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : ECS Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: |
|
