P6IWT-A+ - ECS
PROCESSORS SECC2 Pentium® III processor up to 850MHz(100MHz FSB) and up to 733MHz(133MHz FSB) FC-PGA Pentium® III processor up to 850MHz(100MHz FSB) and up to 866MHz(133MHz FSB) Pentium®II series processors Celeron™ PPGA processors up to 533MHz CHIPSET Intel® 82810 & 82801AA -- Graphics Memory Controller Hub (GMCHE), I/O Controller Hub(ICH) & Firmware Hub (FWH) with following features Integrated graphics controller with 4MB Display Cache AC97 Audio/Modem interface ITE LPC I/O - IT8770F CMI8738 PCI 3D Audio / HSP 56Kflex/V.90 Modem Chip CH7007 Digital PC to TV encoder MEMORY Two 184-pin DIMMs sockets for 3.3V PC100 SDRAM Maximum: 512MB SYSTEM BIOS Award BIOS with 4MB Flash ROM in Firmware Hub(FWH) Supports Plug and Play 1.0A, AMP 1.2, Multi Boot, DMI Full Support for ACPI revision 1.0A specification I/O INTERFACE Supports Plug and Play function One - EPP/ECP mode parallel port Two-16550 high-speed serial I/O ports (1 connector, 1 bracket) Supports 360K~2.88M Byte, 3 Mode FDDs or LS120 Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 33/66) PS/2 keyboard and PS/2 mouse connectors ATX Power Supply Connector Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port) Header for TV-out bracket Two sets of USB connectors VGA Connector Other ports: IrDA/CIR cable Header Green, HDD, Power indicator LED Connectors CPU Fan, Power Fan and Chassis Fan Headers LAN Card Wake Up/Internal Modem Ring Wake-Up Headers RTC & BATTERY 256 bytes CMOS SRAM included in Intel I/O Controller Hub(ICH) With CMOS SRAM hardware clear jumper EXPANSION SLOTS 5 PCI slots, 1 AMR slot FORM FACTOR ATX (304mm*220mm) CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : ECS Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: |
|
