EP-4T2A EPOX
Supports Socket 423 Processors. Intel Pentium® 4 Intel 850 AGPset. Winbond Super Multi I/O Controller. 1 Floppy drive controller, 1 Parallel port (EPP, ECP), 2 Serial ports. USB. 2 supported onboard. 4 support max (optional). Award PnP BIOS. Flash upgradeable. 120MB ATAPI floppy drive and ZIP support! Standard ATX form factor. 305mm x 245mm UltraDMA EIDE Controllers. PCI Bus IDE Port/UDMA100 x 2 (Up to 4 Devices) 400MHz Front Side Bus. 4x RIMM Slots for RAMBUS PC600/PC800. 2GB max. supported. PS/2 connectors. 1 PS/2 mouse, 1 PS/2 keyboard. 5 (32-bit) PCI, 1 CNR, & 1 AGP. AGP supports 4x modes. C-Media CMI8738/PCI-SX PCI sound chip Extended Functions for Greater Value! Supports exclusive USDM(Unified System Diagnostic Manager) and Hardware Monitoring Function by W83627HF-AW Supports exclusive KBPO(Keyboard Power ON) Supports STR (Suspend To RAM) power saving Function Supports CPU Vcore and Clock Setting Supports Wake-On-LAN Function The EP-4T2A is based on the Intel 850 chipset, an AGPset offering a 400MHz Bus Clock, supporting a single Socket 423 Pentium 4 processor. The AGP Slot is compatible with any AGP compliant adapter providing an immediate doubling (or quadruple) in the maxim um available 2D/3D Graphics Bandwidth without reducing performance of other PCI cards. AGP Technology also allows Virtual Reality applications to use as much texture buffer space as they need without expensive card or hardware upgrades. The bundled feature USDM, another exclusive innovation from EPoX and supported by the EP-4T2A, provides you the important real-time information to monitor and control your system for safer and more stable computing in mission-critical Enterprise, Internet and Commerce applications. Quick View...Model Chipset EP-BX5 Intel 82440BX EP-BX6 Intel 82440BX EP-BX7 Intel 82440BX EP-4T2A Intel 850 CPU Pentium II Pentium III Celeron Pentium II Pentium III Celeron Pentium III Celeron Pentium 4 ISA/PCI 2/5 + 1 AGP 1/6 + 1 AGP 1/6 + 1 AGP 0/5 + 1 AGP + 1 CNR SIMM/DIMM 0/4 0/3 0/4 0/0 + 4 RIMM BIOS Award/Flash EPROM Award/Flash EPROM Award/Flash EPROM Award/Flash EPROM Switching Regulator Yes Yes Yes Yes Form Factor ATX ATX ATX ATX Others UltraDMA-33/ACPI** 2S/1P/USB IDE/FDD ports KBPO, USDM, WOL, SB-LINK UltraDMA-33/ACPI** 2S/1P/USB IDE/FDD ports KBPO, USDM, WOL, SB-LINK, POST UltraDMA-33/ACPI** 2S/1P/USB IDE/FDD ports KBPO, USDM, WOL, SB-LINK, POST UltraDMA-100/ACPI** 2S/1P/USB IDE/FDD ports KBPO, USDM, WOL CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : EPOX Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: Problémy, zkušenosti, tipy, triky.....: |
|
