Stallion ATX-R653 SYSTEM BOARD - M Technology
Stallion ATX-R653 SYSTEM BOARD -------------------------------------------------------------------------------- (Click for larger image) FEATURE HIGHLIGHTS Based on the Intel 82440FX PCI Chipset Supports Fast Page Memory Supports EDO Memory Supports Intel Pentium II - 233MHz to 300MHz Slot 1 Processors The M Technology R653 provides the latest enhancements in system board technology. Based on the Advanced Intel 82440FX PCIset, the board provides high PCI-to-memory bandwith for today's demanding applications. The processor support ranges from the fastest Specifications: Processor: Supports Dual Slot 1 Processors Intel Pentium II Processor Card (with internal 256 / 512 KB cache) Chipset: Intel 8244FX PCI Chipset Expansion Slots: Four 32-Bit Bus Mastering PCI Slots Four 16-Bit ISA Slots (One pair of sharable PCI/ISA Slots) System Memory: Six 72pin SIMM Slots (8/16/32/64/128 MB Module) Supports Maximum of 768MB EDO RAM On Board IDE: 2 X IDE Connectors For Up To 4 IDE Drives - PIO Mode 4 Transfers - PCI Bus Master Mode IDE Interface I/O On Board: One FDD Port (Supports 360/720KB, 1.2/1.44/2.88 MB FDD) Two RS-232 Serial Ports (16550 UART Compatible) One Parallel Printer Port (SPP/EPP/ECP Mode) IrDA Port with Optional Cable for Transceiver/Receiver PS/2 Mouse Port On Board USB: Universal Serial Bus Controller - Host / HUB Controller - Two USB Port Connectors BIOS: Award Pentium PCI BIOS With Green, Plug & Play Functions - Supports Multiple Boot From E-IDE/SCSI/CD-ROM/FDD/LS-120 - 2MB Flash ROM Board Size: 4-Layer of PCB, 30.4cm X 24.4cm (12" X 9.6") ATX Form Factor Documentation: Complete User Installation Manual Quality Commitment: The continuously evolving technology of the computer industry demands the highest level of quality, reliability and compatibility. M Technology is committed to providing the industry's state-of-the-art manufacturing, testing, and customer support. The R653 is extensively tested for compatibility under various operating systems, including: OS/2TM Warp SCO® UNIX ODT MS-DOSTM v 5.0, 6.2 NOVELL WindowsTM v 3.1, 95 & NTTM PC-DOS CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : M Technology MTechnology M-Technology Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě |
|
