SY-5EMA+- SOYO
Model SY-5EMA+ Description - 100MHz Host Bus Pentium Processor Based ATX Mainboard with AGP Port Processor 321-pin ZIF Socket 7 - Intel Pentium Processor with MMX Technology up to 233MHz - Supports AMD-K6 (166~300 MHz) and AMD-K6-2 (266~450 MHz) and AMD-K6-3 400 MHz* - Supports Cyrix /IBM 6x86MX (PR200 ~ 266), 6x86MII (300 ~ 366) - Supports IDT WinChip2(200~300) and WinChip (266~300) - Supports Rise (PR233 ~ 266) Chipset - ETEQ 82C6638/6629 AGP Chipset L2 Cache - 1MB Pipelined Burst SRAM on board System Memory - Three 168-pin DIMM sockets (8/16/32/64/128/256MB Module) - Supports up to 768MB EDO and SDRAM Expansion Slots - 1 x 124 bit AGP slot - 5 x 32-bit Bus Mastering PCI slots - 2 x 16-bit ISA slots (One shareable PCI/ISA slot) On Board Ultra I/O Chip - SMC 37C669 Super I/O chip - 2 x RS-232 serial ports (16550 UART compatible) - 1 x Parallel printer port (SPP/EPP/ECP mode) - Provides IrDA port with optional cable for transceiver Two Ultra DMA-33 IDE ports - Supports two independent channels for four IDE devices - Supports up to PIO mode 4 and Ultra DAM/33 - 2 x PCI bus mastering ATA E-IDE ports Boot-Block Flash BIOS - Award PCI BIOS with green, plug and play, DMI functions - Supports multiple-boot from E-IDE / SCSI /CD-ROM / FDD /LS120 / ZIP, and Year 2000 compliant - 1 Mbit Flash ROM Board Dimensions - Four layers, 30.5 cm x 19 cm (12" x 7.5") - ATX form factor Double Stack Back-Panel I/O Connectors - PS/2 Mini-DIN mouse & keyboard ports - 2 x USB ports - 2 x D-Sub 9-pin male Serial ports - 1 x D-Sub 25-pin female printer port FCC Class B and CE EMI Regulation Compliant CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : SOYO Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: |
|
