Thunder K8QS (S4880) - TYAN motherboard
Specifications Processor • Quad µPGA 940-pin ZIF sockets • Supports up to four AMD Opteron™ 800 series processors • Four onboard 3-phase VRMs • Integrated 128-bit DDR memory controller Chipset • AMD-8131™ HyperTransport™ PCI-X Tunnel • AMD-8111™ HyperTransport™ I/O Hub • Winbond™ W83627HF Super I/O ASIC • Total five Hardware Monitoring IC: • One ADM1027 and four LM63 Memory • 128-bit dual channel memory bus • Ten 184-pin 2.5-Volt DDR DIMM sockets - 4 on CPU 0 and 2 each on CPU 1, 2, and 3 • Supports up to 20GB of Registered DDR • Supports ECC and ECC with Chipkill type • memory modules • Supports DDR 400 / 333 / 266 / 200 Expansion Slots • Two independent PCI-X buses • Two 64-bit 66/33 MHz (3.3-Volt) PCI-X slots - from PCI-X bridge A • Two 64-bit 133/100/66/33 MHz (3.3-Volt) PCI-X slots - from PCI-X bridge B • One Legacy 32-bit 33MHz (5-Volt) PCI slot • Total of five usable slots Integrated I/O • One floppy connector supports one device • Two 9-pin serial ports (1 connector & 1 header) - and one 25-pin parallel port pin-header • PS/2 mouse and keyboard connectors • Two USB v1.1 front panel headers • Two USB v2.0 connectors through VT6212 System Management • Nine 3-pin fan headers with tachometer monitoring • Four fan headers with (PWM) speed control • One 2-pin Chassis Intrusion header • Temperature, voltage and fan monitoring Integrated Enhanced IDE Controller • Provides two IDE dual-drive ports for up to four EIDE devices • Supports for UDMA 33/66/100/133 IDE drives • and ATAPI compliant devices Integrated LAN Controllers • Broadcom BCM5704C dual-channel GbE LAN - Two RJ-45 LAN connectors with LEDs - Connected to PCI-X Bridge A • Two Front Panel LED headers Integrated PCI Graphics • ATI® RAGE™ XL 8MB PCI graphics controller Integrated SATA RAID Controller (option) • One Silicon Image SI3114 controller • Four Serial ATA 1.0 ports • Supports up to four SATA drives • Supports RAID 0, 1, 10 Integrated Dual Channel SCSI (option) • LSI® 53C1030 U320 SCSI controlelr • Dual-channel U320 SCSI • Connects to PCI-X Bridge A • Supports LSI® ZCR (Zero Ch. RAID) Intelligent Platform Management Interface Header • TYAN Server Management Daughter card (optional) supports features listed below via IPMI header • QLogic™ Zircon Baseboard Management Controller (BMC) based on powerful ARM7 technology • Tailored for IPMI highest 1.5 Spec. • Supports KCS and BT styles • Flexible Windows & Linux Management Solution • Supports RMCP and SNMP protocols • Supports ASF standard and EMP • I2C serial multi-master controllers and UARTs • Build-in IPMB connector • Remote power on/off and reset support (IPMI-over-LAN) BIOS • Phoenix BIOS; 4Mbit LPC Flash ROM • Watchdog timer • USB boot support • 48-bit LBA Support • Supports PXE via Ethernet • ACPI 2.0 & 1.0B support Form Factor • SSI MEB footprint (13"x16"; 330x407mm) • EPS12V power connectors • Serial (one) and VGA (one) connectors • Stacked USB 2.0 (two) connectors • Stacked PS/2 keyboard and mouse connectors • Two RJ-45 side-by-side LAN connectors with LEDs Regulatory • FCC Class B (Declaration of Conformity) • European CE (Declaration of Conformity). CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : TYAN Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě |
|
